Powertrain
Engine Type4 stroke, V-twin, Differential Integrated, Liquid Cooling
Power976 cc, 71 hp @ 6500 rpm
Cold Cranking-40 Degree Celsius
Fuel SystemEFI, Gasoline
TransmissionAutomatic (CVT)
No. of GearsL - H - N - R - P (5 positions)
Seat CapacityFour
Technical Specifications
Front ShocksCoil Over Dual Rated Nitro
Front SuspensionDouble Wishbone
Rear ShocksCoil Over Dual Rated Remote Canister
Rear SuspensionTrailing ARM With Triple Camber Links
Front & Rear BrakesDisc
Front & Rear Tires31 x 11.5
Wheel SizeAlloy R15 - 7"
Length X Width X Height3995 mm X 1950 mm X 2000 mm
Wheelbase3412 mm
Track Width1653 mm
Cargo Capacity400 kg
Payload Capacity700 kg
Dry Weight1300 Kg
Fuel Tank Capacity30 L
Ground Clearance381 mm
Cargo SystemIn built cargo box
Transmission Modes2WD, 4WD, Front & Rear + Open & Lock Differential Modes
Chassis/ CageSpace Frame
Hitch TypeSingle Point (Front & Rear)
Seat Type / Seat BeltBucket / 4 point / 5 point
SnorkelInlet & Outlet for CVT
Customisations
Open / Closed Cabin
Air Conditioning, Climate Control
Drone Carrier, Drone Launcher, Drone Charger, Anti Drone
Reconnaissance & QRT Configuration
Mission specific customisation available across all DDS platforms
